9.6 Terminal Box Parts
Component
No.
Part Name
Parts
Per
Hoist
RHN08, RHN10
208, 230V
460, 575V
A275
RPU Overload Device (SLE21)
1
RHN0500
RHN0500
RPU Overload Device (SLE22)
RHN0575
RHN0575
F41-F43
Fuse Holder
3
RHN0501
RHN0501
Fuse Link
3
RHN0529
RHN0502
F101-F102
Fuse Holder
2
RHN0501
RHN0501
Fuse Link
2
RHN0541
RHN0518
G21
Rectifier
1
RHN0542
RHN0504
K10
Contactor
,
Mainline
1
RHN0543
RHN0519
K23-K24
Contactor
,
Hoist Directional
2
RHN0543
RHN0519
Auxiliary Contact Block
1
RHN0505
RHN0505
K25
Contactor
,
Hoist Speed
1
RHN0537
RHN0520
K29
Contactor, Hoist Brake
1
RHN0528
RHN0528
K41-K42
Contactor
,
Trolley Directional
1
RHN0509
RHN0509
K45
Contactor
,
Trolley Speed
1
RHN0510
RHN0510
Q29
Circuit Breaker
1
RHN0544
RHN0521
Auxiliary Contact Block
1
RHN0521
RHN0522
S220
Gear-Type Limit Switch
1
RHN0511
RHN0511
T100
Transformer*
1
RHN0545
RHN0523 (*460V)
RHN0524 (*575V)
N/A
Transformer Fuse
1
9006278
9006202
X16
PE -Terminal
1
RHN0530
RHN0527
Terminal
3
RHN0531
RHN0526
PE -Terminal
1
RHN0525
RHN0525
Terminal
2*
RHN0533 (*Qty=6)
RHN0515
PE -Terminal
5
RHN0516
RHN0516
Terminal
20
RHN0517
RHN0517
