9.4 Rope Suspension Parts
Figure
No.
Part Name
Parts Per
Hoist
RHN15U
RHN15D RHN20D
1
Clamp
1
RHN0324
RHN0253
2
Wire rope clamp
1
RHN0329
RHN0254
5
Load sensor assembly
1
RHN0332
RHN0255
6
Load sensor (SLE21 ONLY)
1
RHN0559
Load sensor (SLE22 and SLE21
1
)
RHN0569
8
Rope suspension
1
RHN0334
RHN0257
10
Bearing pedestal
4
RHN0325
RHN0258
11
Safety bolt
8
9093372
12
Locknut
8
9098511
15
Deflection cross bar
1
RHN0326
RHN0259
16
Rope pulley
1
RHN0327
RHN0260
20
Block operated limit switch
1
RHN0550
1 Not all leads utilized on SLE21
