2 dimensions – Harrington Hoists and Cranes RHN - Rhino Wire Rope Hoist User Manual
Page 11
11
2.2
Dimensions
Figure 2-1
2-10 ton Deck Mounted Hoist
Dimensions (See
Table 2-4
)
Figure 2-2
15-20 ton Deck Mounted Hoist
Dimensions (See
Table 2-5
)
Table 2-4
Deck Mounted Hoist Dimensions (2-10 ton)**
Capacity
(Tons)
Product Code*
Min. Headroom
C
(in)
e1
(in)
e2
(in)
e3
(in)
e4
(in)
e5
(in)
e6
(in)
e7
(in)
e9
(in)
e10
(in)
e11
(in)
e13
(in)
e14
(in)
e15
(in)
e16
(in)
eA
(in)
2
RHN02D-20A-20D-
22.6
40.9
29.6
6.3
4.6
9.0
4.8 13.9 21.3 11.5 4.9
7.2
6.3 11.0
13.3 22.2
RHN02D-33A-20D-
52.5
6.2
7.6
22.1 33.8
3
RHN03D-20A-20D-
22.6
40.9
29.6
6.3
4.6
9.0
4.8 13.9 21.3 11.5 4.9
7.2
6.3 11.0
13.3 22.2
RHN03D-33A-20D-
52.5
6.2
7.6
22.1 33.8
5
RHN05D-20B-20D-
25.6
41.3
31.2 6.4
4.3
11.2 5.9 14.3 22.0 13.8 6.6
8.8
7.2 12.9
13.5 22.2
RHN05D-33B-20D-
52.9
7.2
22.2 33.8
7 ½
RHN08D-20C-20D-
32.5
48.0
39.3 9.5
4.6
14.1 7.5 17.2 28.6 18.2 8.6 11.7 9.4 16.9
12.6 24.6
RHN08D-33C-20D-
60.4
7.8
21.8 37.0
10
RHN10D-20C-20D-
32.5
48.0
39.3 9.5
4.6
14.1 7.5 17.2 28.6 18.2 8.6 11.7 9.4 16.9
12.6 24.6
RHN10D-33C-20D-
60.4
7.8
21.8 37.0
Table 2-5
Deck Mounted Hoist Dimensions (15 & 20 ton)**
Capacity
(Tons)
Product Code*
Min. Headroom
C
(in)
e1
(in)
e2
(in)
e3
(in)
e4
(in)
e6
(in)
e7
(in)
e10
(in)
e16
(in)
eA
(in)
15
RHN15D-20D-16D-
37.0
54.4
43.7 13.4
4.6
10.9 19.5 29.7
15.7
29.7
RHN15D-33D-16D-
66.6
7.6
24.9
41.9
20
RHN20D-20D-16D-
37.0
54.4
43.7 13.4
4.6
10.9 19.5 29.7
15.7
29.7
RHN20D-33D-16D-
66.6
7.6
24.9
41.9
Notes:
*See Section 2.1.1 for place holder
designation
** See
Table 2-10
and
Table 2-11
for attachment point dimensions
