Harrington Hoists and Cranes RHN - Rhino Wire Rope Hoist - Manual (Page 82)

82
9.4 Rope Suspension Parts
Figure
No.
Part Name
Parts
Per
Hoist
RHN02 RHN03 RHN05 RHN08 RHN10
1 Clamp 1 RHN0024 RHN0110 RHN0173
3 Wire rope clamp 1 RHN0025 RHN0111 RHN0174
18
Suspension traverse (20 ft lift), Deck Mounted
1
RHN0026
Suspension traverse (33 ft lift), Deck Mounted RHN0027
19
Suspension traverse (20 ft lift), Deck Mounted
1
RHN0112
Suspension traverse (33 ft lift), Deck Mounted RHN0113
20
Suspension traverse (20 ft lift), Deck Mounted
1
RHN0177
Suspension traverse (33 ft lift), Deck Mounted RHN0178
21 Suspension 1 RHN0114
22 Suspension 1 RHN0028 RHN0179
25 Bushing 1 RHN0029 RHN0115 RHN0180
30
Deflection cross bar – 20ft lift
1
RHN0030 RHN0116 RHN0181
Deflection cross bar – 33ft lift RHN0031 RHN0117 RHN0182
31 Rope pulley 1 RHN0032 RHN0118 RHN0191
32 Bushing 2 RHN0034 RHN0120 RHN0186
35 Block operated limit switch (BLS) 1 RHN0550
