6 terminal box parts – Harrington Hoists and Cranes RHN - Rhino Wire Rope Hoist User Manual
Page 104
104
9.6 Terminal Box Parts
Component
No.
Part Name
Parts
Per
Hoist
RHN15D, RHN20D
A275
RPU Overload Device (SLE21)
1
RHN0500
RPU Overload Device (SLE22)
RHN0575
F41-F43
Fuse Holder
3
RHN0501
Fuse Link
3
RHN0529
F101-F102
Fuse Holder
2
RHN0501
F101-F102
Fuse Link
2
RHN0502
G21
Rectifier
1
RHN0504
K10
Contactor,
Mainline
1
RHN0536
K23-K24
Contactor,
Hoist Directional
2
RHN0536
Auxiliary Contact Block
1
RHN0505
K25
Contactor,
Hoist Speed
1
RHN0537
K29
Contactor
, Hoist Brake
1
RHN0528
K41-K42
Contactor,
Trolley Directional
1
RHN0509
K45
Contactor,
Trolley Speed
1
RHN0510
Q29
Circuit Breaker
1
RHN0522
Q29
Auxiliary Contact Block
1
RHN0521
S220
Gear-Type Limit Switch
1
RHN0511
T100
Transformer
4V
1
RHN0534
5V
RHN0535
N/A
Transformer Fuse
1
9006278
X16
PE-Terminal
1
RHN0532
Terminal
3
RHN0533
PE-Terminal
1
RHN0527
Terminal
2
RHN0515
PE-Terminal
5
RHN0516
Terminal
20
RHN0517
