Mechanical Mounting
Review the Configuration Drawing which is included in the
Drawing Chapter of this manual.
Please reference the dimensional drawings located in the
Drawing Chapter of this manual when installing the
equipment.
Consider the following general guidelines when mounting the
sensor and detector:
Avoid internal vessel obstructions such as baffles, agitators,
manways, heater/cooler tubes, etc. which could interfere with
the transmission through the vessel of the radiation's "active
beam."
The source and detector must be rigidly mounted so they do
not move with respect to each other. Such movement will
destroy the system's calibration and/or its measurement.
Insulation must be used at the point of installation IF:
- the temperature of the vessel at that spot exceeds 120
o F
(50 o C), or - the voltage transmission through the vessel could
interfere with the signal transmission from the source to the
detector.
