18
Analog Out Config
The Analog Out Config menu is used to set where the source of power is. It contains the following items:
ITEM FUNCTION
Loop 1 Shows and allows the user to assign a source to Loop 1
MLM Output 1 Shows and allows the user to assign a source to MLM1
MLM Output 2 Shows and allows the user to assign a source to MLM 2
Power Source Shows and allows the user to set where the source of power is internal or external,
to power the AO modules outputs
HART Menu
The Hardware menu is used to provide information about the HART interface. It contains the following items:
ITEM FUNCTION
Tag Name Shows and allows the user to set the device tag name
MultiDrop Shows and allows the user to set the multi-drop address for a device (or 0 if the
device is not used on a multi-drop loop)
Univ Rev Shows the HART universal command revision to which this device is conformant
Spec Rev Shows the HART specification revision to which this device is conformant
System Menu
The System menu is used to provide information about the X96S. It contains the following items:
ITEM FUNCTION
Serial # Shows the device serial number
Hardware Rev Shows the device hardware revision
Software Rev Shows the device software revision
Date Shows and allows the user to set the date
Hour (0-23) Shows and allows the user to set the hour
Minute Shows and allows the user to set the minute
Password Shows and allows the user to set a password from the main display to allow
access to all menus
Date/Time Format Shows and allows the user to set the date/time format used on the status display
Date/Time Format is one of the following:
Date/Time Format MEANING
mm/dd/yy hh:mm:ss North American date and 24 hour time
mm/dd/yyyy hh:mm:ss North American Y2K date and 24 hour time
mm/dd/yy hh:mm:ss
am/pm
North American date and 12 hour time with am/pm indication
dd-mm-yy hh:mm:ss European date and 24 hour time
dd-mm-yyyy hh:mm:ss European Y2K date and 24 hour time
dd/mm/yy hh:mm:ss European date and 24 hour time
dd/mm/yyyy hh:mm:ss European Y2K date and 24 hour time
