Model GFC7001T Carbon Monoxide Analyzer
Teledyne
Analytical
Instruments
iii
INFORMATION ABOUT THE SPECIFIC CONFIGURATION OF YOUR
MODEL GFC 7001T CARBON MONOXIDE ANALYZER
Selected Versions of the Model GFC 7001T
M
ODEL
GFC
7001T—
S
TANDARD
V
ERSION
This Model GFC7001T CO Analyzer is a touch screen version designed for analyzing the CO concentration in a
background gas specified by the customer. It has a minimum settable range of 0-1 ppm and a maximum settable
range of 0-1000 ppm. The standard version is designed for positive pressure applications. The analyzer may have
one or two analysis ranges with or without auto-ranging as listed below. Alarm relays are included with this
version.
M
ODEL
GFC
7001TA
—
A
MBIENT
P
RESSURE
V
ERSION
The Model GFC7001TA CO Analyzer is a touch screen version designed for analyzing the CO concentration in a
background gas specified by the customer. It has a minimum settable range of 0-1 ppm and a maximum settable
range of 0-1000 ppm. The TA version is designed for ambient pressure applications. The analyzer may have one or
two analysis ranges with or without auto-ranging as listed below. Alarm relays are an optional feature and if
included, that option will be checked below.
M
ODEL
GFC
7001TU
—
U
LTRA
L
OW
R
ANGE
V
ERSION
The Model GFC7001TU CO Analyzer is a touch screen version designed for analyzing trace CO concentrations in
a background gas specified by the customer. It has a minimum settable range of 0-100 ppb and a maximum settable
range of 0-100 ppm. The TU version is designed for positive pressure applications. The analyzer may have one or
two analysis ranges with or without auto-ranging as listed below. Alarm relays are an optional feature and if
included, that option will be checked below.
P
OWER
R
EQUIREMENTS
This Model GFC 7001T is configured to operate from the following AC Power source:
100-120 VAC 60 Hz
220-240 VAC 60 Hz
100V 60 Hz
100-120 VAC 50 Hz
220-240 VAC 50 Hz
100V 50 Hz
A
NALOG
O
UTPUT
S
IGNALS
Analog output signals are available at A1 and A2 on the rear panel. This instrument is configured with the
following analog outputs:
A1: 4-20 mA
A2: 0-5 V
A2: 4-20 mA
R
ANGE
M
ODE
The analyzer can be designed with a single or dual analysis ranges with auto-ranging or dual independent ranges.
This analyzer is configured with the following range mode:
Single Range:
Dual Range/Auto-ranging:
Dual Range/Independent:
Low Range:
Low Range:
High Range:
High Range:
