Continuous Control Functions

PID BLOCK CROSS REFERENCE

A-3

Field Name

Mnemonic

Attr

Remote Setpoint Range High

RSPRH

25

Remote Setpoint Range Low

RSPRL

26

Remote Setpoint Ratio Input

RSPRI

86

Remote Setpoint Ratio Quality

RSPRQ

33

Remote Setpoint Ratio, Initial Value

RSPR

32

Reset Rate Base Value

BRESET

62

Reset Rate Modifier Integral Response Input

IRMI

84

Setpoint Limit High

SPLH

27

Setpoint Limit Low

SPLL

28

Setpoint Mode Command

SPMC

19

Setpoint Mode Restart Value

SPMRV

70

Setpoint Mode Status Quality

SPMSQ

18

Setpoint Mode Status, Initial Value

SPMS

17

Setpoint Modes Allowed

SPMA

16

Setpoint Modes Limited

SPML

30

Setpoint Restart Value

SPRVI

77

Setpoint Selector A Input

SPSAI

89

Setpoint Selector B Input

SPSBI

90

Setpoint Selector Type

SPSTYPE

29

Setpoint Track Enable

SPTE

20

Setpoint Track Input

SPTI

81

Setpoint, Initial Value

SP

23

Track Command Input

TCI

80

Track Status

TS

54

Track Status Quality

TSQ

55

Unlimited Output

UOP

44

Unlimited Output Quality

UOPQ

45

Version

VERSION

00
