Continuous Control Functions
RAMP SOAK BLOCK
3-8
Table 3-1. RSK Block Attributes, Valid Values, Mnemonics, and Data Types
Field Name
Mnemonic
Valid Values
CWR Data type
Attr
Version
VERSION
--R
Long State
00
Block Length
BLKLEN
--R
Count
01
State
STATE
RUN (0), HOLD (1), OFF (2), DEBUG (3).
CWR Short State
02
Bad Inputs
BADINP
REJECTED (0), ACCEPTED (1).
CWR Discrete
03
Repeat Profile
REPEAT
NO (0), YES (1). Default is NO
CWR Discrete
04
Use Output States
USE
NO (0), YES (1). Default is NO
C-R Discrete
05
Startup Type
STYPE
START VALUE (0) - Default is START.
TRACK VALUE (1)
PROCESS VALUE (2)
CWR Short State
06
Restart Mode
RESMODE
RUN (0)
HOLD (1)
PREVIOUS (2) Default value is PREVIOUS.
CWR Short State
07
Restart Segment
RESSEG
PRESET (0 to 36) or PREVIOUS (255)
Default value is PREVIOUS.
CWR Long State
08
Seg
(Number of Segments)
NUMSEG
Value 1 through 36 is allowed. Default is 1.
C-R Long State
09
Command
CMD
The value read from this location will always
be 0. The following values, when written to
this location, will be interpreted as commands:
RESET (1)
STOP (2)
HOLD(3)
RUN(4)
SKIP(5)
-WR Long State
10
Soak Hysteresis
SHYST
Valid values are 0.0 or greater. Default is 0.0
CWR Floating pt
11
Ramp Hysteresis
RHYST
Valid values are 0.0 or greater. Default is 0.0
CWR Floating pt
12
Start Value
START
Default is 0.0
CWR Floating pt
13
Result
R
CWR Floating pt
14
Result Quality
RQ
GOOD (0), BAD (1).
-WR Discrete
15
State A
SA
CWR Discrete
16
State A Quality
SAQ
GOOD (0), BAD (1).
-WR Discrete
17
State B
SB
CWR Discrete
18
State B Quality
SBQ
GOOD (0), BAD (1).
-WR Discrete
19
State C
SC
CWR Discrete
20
State C Quality
SCQ
GOOD (0), BAD (1).
-WR Discrete
21
State D
SD
CWR Discrete
22
State D Quality
SDQ
GOOD (0), BAD (1).
-WR Discrete
23
Active Segment
Number
ACTSEG
Value zero indicates the profile is not active.
CWR Long State
24
Active Segment
Number Quality
ACTSEGQ GOOD (0), BAD (1).
-WR Discrete
25
Time Remaining
TREM
Is the time remaining in a segment.
CWR Msec time
26
Time Remaining
Quality
TREMQ
GOOD (0), BAD (1).
-WR Discrete
27
Cycle Number
CYCNUM
0 to 65535. The cycle number stops counting
once the number reaches 65535.
CWR Count
28
Cycle Number Quality
CYCNUMQ
GOOD (0), BAD (1).
-WR Discrete
29
