Continuous Control Functions

PID BLOCK CROSS REFERENCE

A-1

APPENDIX A

PID BLOCK CROSS REFERENCE

A.1 GENERAL

Table A-1 list all the PID attributes by their field name.

Table A-1. PID Attributes Sorted by Field Name

Field Name

Mnemonic

Attr

Active Setpoint Quality

SPQ

24

Adjusted Remote Setpoint Quality

ARSPQ

22

Adjusted Remote Setpoint, Initial Value

ARSP

21

Bad Inputs Accepted

BADINP

03

Bias Quality

RSPBQ

35

Block Length

BLKLEN

01

Block State

STATE

02

Calculation Error Active

CERRA

08

Calculation Error Active Quality

CERRAQ

09

Calculation Error Unacknowledged

CERRU

06

Calculation Error Unacknowledged Quality

CERRUQ

07

Calculation Error

CERRS

05

Calculation Error Action

CERRACT

58

Control Action

ACTION

57

Control Algorithm Type

CATYPE

59

Control Interval

CI

15

Control Mode

CMS

67

Control Mode Command

CMC

69

Control Mode Restart Value

CMRV

72

Control Mode Status Quality

CMSQ

68

Control Modes Allowed

CMA

66

Dead Time Compensation Input

DTCI

76

Deviation

DEV

38

Deviation Quality

DEVQ

39

Diagnostic Group

SUPPGRP

04

External Feedback Input

EFBI

79

Feedforward Calculation Type

FFCTYPE

56

Feedforward Compensation Input

FFCI

78

Gain Base Value

BGAIN

61

Gain Modifier Proportional Response Input

PRMI

83
