Continuous Control Functions

RAMP SOAK BLOCK

3-9

Field Name

Mnemonic

Valid Values

CWR Data type

Attr

Mode

MODE

RUN (0)
HOLD (1)
TRK (3)

CWR Short State

30

Mode Quality

MODEQ

GOOD (0), BAD (1).

-WR Discrete

31

Return Mode

RETMODE

RUN (0), HOLD (1)

--R

Short State

32

Bad Track Input

BADTRK

REJECTED (0), ACCEPTED (1).

CWR Discrete

33

Process Input

PROCINP The initial local value default is 0.0

CWR Floating pt

34

Track Input

TRKINP

Track Input value or source pointer.
The initial local value default is 0.0

CWR Floating pt

35

Track Command
Input

TCMDINP Track Command Input value or source

pointer. If the value is true the mode status will
be TRACK. The initial local value default is
false.

CWR Discrete

36

Reset Input

RESINP

NONE, local data or source pointer.
The initial local data value is 0.

CWR Discrete

37

Stop Input

STOPINP

NONE, local data or source pointer.
The initial local data value is 0.

CWR Discrete

38

Run Input

RUNINP

NONE, local data or source pointer.
The initial local data value is 0.

CWR Discrete

39

Hold Input

HOLDINP

NONE, local data or source pointer.
The initial local data value is 0.

CWR Discrete

40

Skip Input

SKIPINP

NONE, local data or source pointer.
The initial local data value is 0.

CWR Discrete

41

Segment 1 Target
Value

TVS1

Default value is 0.0

CWR Floating pt

101

...etc 2 through 35

...

...

Segment 36 Target
Value

TVS36

Default value is 0.0

CWR Floating pt

200

Segment 1 Time
Interval

TIS1

Default value is 0.

CWR Msec time

201

...etc 2 through 35

...

...

Segment 36 Time
Interval

TIS36

Default value is 0.

CWR Msec time

300

Segment 1
Guaranteed

GTS1

NO (0), YES (1). Default is NO.

CWR Discrete

301

...etc 2 through 35

...

...

Segment 36
Guaranteed

GTS36

NO (0), YES (1). Default is NO.

CWR Discrete

400

Segment 1 State A

SAS1

FALSE (0), TRUE (1). Default is FALSE.

CWR Discrete

401

...etc 2 through 35

...

...

Segment 36 State A

SAS36

FALSE (0), TRUE (1). Default is FALSE.

CWR Discrete

500

Segment 1 State B

SBS1

FALSE (0), TRUE (1). Default is FALSE.

CWR Discrete

501

...etc 2 through 35

...

...

Segment 36 State B

SBS36

FALSE (0), TRUE (1). Default is FALSE.

CWR Discrete

600

Segment 1 State C

SCS1

FALSE (0), TRUE (1). Default is FALSE.

CWR Discrete

601

...etc 2 through 35

...

...

Segment 36 State C

SCS36

FALSE (0), TRUE (1). Default is FALSE.

CWR Discrete

700

Segment 1 State D

SDS1

FALSE (0), TRUE (1). Default is FALSE.

CWR Discrete

701

...etc 2 through 35

...

...

Segment 36 State D

SDS36

FALSE (0), TRUE (1). Default is FALSE.

CWR Discrete
