Magpix front & right side – Luminex MAGPIX Installation and Hardware User (IVD) User Manual
Page 44
Luminex IVD MAGPIX Hardware Installation and User Manual
32
FIGURE 37.
1
3
5
4
2
6
MAGPIX Front & Right Side
1
Status indicator light
2
Soft on/off switch
3
Access door for plate carrier.
4
Access door for fluid compartment. For a more detailed illustration, see
Figure 46 on page 41.
5
Side access door
6
Side access door latch
