15
Installation Procedure
4. Fold down the cardboard panels from each side of the instrument.
FIGURE 15. Removing the Packing Materials
5. Pull the plastic bag down from the top.
6. Place MAGPIX onto a lab bench or other flat, stable surface. This may require two
people.
Before proceeding with the installation, check the contents of the overpack with the
checklist on page 29 and make certain you can locate all listed items. Check contents to
make certain no damage has occurred during shipping. If anything is missing or damaged,
contact Luminex Technical Support (in the U.S. and Canada, 1-877-785-BEAD

(-2323); outside of the U.S. and Canada, +1 512-381-4397; in Europe, +31 162 408 333).
Connecting the Components
To connect the components:
1. Locate the cords in the accessory tray of the overpack.
FIGURE 16. Power Cord and USB Cable
