17
Installation Procedure
Preparing MAGPIX
Preparing MAGPIX includes removing the shipping plug, installing the Drive Fluid, and
installing the sample probe.
Removing the Shipping Plug
Inside the side access door of MAGPIX, a shipping plug holds the sample probe assembly
in place. Use the door access tool included in the accessory tray to open the side access
door and remove the plug.
CAUTION: MAGPIX should not be plugged into a power source when you
open this compartment.
To open the side access door and remove the shipping plug:
1. Locate the door access tool in a small plastic bag in the accessory tray of the overpack.
FIGURE 19. Door Access Tool
2. Insert the tool in the side access door latch and turn it one quarter turn clockwise.
FIGURE 20. Door Access Toll Inserted and Turned
3. Slide the door to the right.
