Within the overpack are separate cartons for the PC, the monitor, the 2-pack of Drive
Fluid, and the MAGPIX instrument. In addition, a divided tray contains the cables, CDs,
and printed material.
FIGURE 10. Inside the Overpack
1
2
3
4
Each individual carton can be handled by one person. The MAGPIX carton and the PC
carton each weigh less than 40 pounds (18.14 kg).
Unpacking and Assembling the PC
Begin the installation process with the PC. The computer and monitor are in the boxes at
the end of the overpack (See Figure 10.); the monitor stand is in a box underneath the
accessory tray.
The computer and monitor boxes include all the necessary cords and peripheral devices
as well as complete installation instructions. Follow those instructions to set up the PC.
To set up the PC:
1. Remove the three boxes containing PC components from the overpack.
2. Assemble the components using PC Installation Instructions or the instructions
provided by the PC vendor. Both are in the PC boxes.
1 PC carton
2 Monitor carton
3 Accessory tray (monitor stand and Drive Fluid cartons are
underneath)
4 MAGPIX carton
