21

PC850 Base Configuration Settings:

The PC850 Configure tab allows you to view and edit base and Beltpac settings, including:

• Configuration – Base Configuration (wiring configuration), Base Identifier, Scan Frequencies

Intercom Configuration Input Level and LCD Contrast Level.

• Receivers – frequency, squelch, audio level, enable
• Transmitters – frequency, power, transmitter mode, output mix levels
• Beltpac functions – buttons, frequencies, transmitter power and mode, LED operation

Base Station Mode Configuration:

You can select the Base Station mode from the Configure Tab >Edit Base Configuration Box
>Base>Config>Base Configuration Section

as shown below:

SECTION 5. PC850 BASE CONFIGURATION
