1150 - 73
C
ONFIGURATION
Value / selection
Description
Inhibit program start
Program start
Program stop
Program cancel
Program selection
Fast forward
Segment change
Program cannot be started
Program start
Program stop
Program cancel
Programselection (see below)
Dynamic speed increase of program sequence
Segment change
Display text
Standard text
Text 1
...
Text 100
No text
System texts according to function
Definable texts (only via setup program)
No entry in event list
Delay
0 to 9999 s
An info or an alarm is only activated with delay
(see "Message types")
Message
No
Yes
Defines whether an info is produced when the logic function is activated.
Alarm
No
Yes
Defines whether an alarm message is produced when the logic function is
activated.
Alarms must be acknowledged.
•
Should the info be displayed immediately:
just set info to “yes”
•
Should the info be displayed after a delay:
set info to “yes” and enter delay time
•
Should the alarm be displayed immediately:
just set alarm to “yes”
•
Should the alarm be displayed after a delay:
set alarm to “yes” and enter delay time
•
Should the info change to alarm after a delay time:
set info and alarm to “yes” and enter delay time.
Message types
Logic input 1 (2 to 6) / ...
Limit comparator 1 (2 to 16) / ...
Logic 1 (2 to 8) / ...
Control contact 1 (2 to 8) / ...
Tolerance band signal / ...
Program end signal / ...
Ramp end signal 1 (2 to 4) / ...
