48 - 1150
C
ONFIGURATION
Parameters and functions at the configuration level
General
The following applies to the representation of parameters and functions at the configuration level:
The parameter is not displayed or cannot be selected if
• the instrument features do not permit the function assigned to the parameter.
Example:
Output 3 cannot be configured if no output 3 is available in the instrument.
• the parameter is irrelevant to the function that has been configured.
Example:
Analog input 1 is configured to “Pt100”, which means that display start and end for standard signals
cannot be selected.
Access code
Factory-set code: 0002
E.G. Analog selector
NOTE Some parameters are only available for a fixed-setpoint controller (with or without ramp
function) or a program controller/generator. For fixedsetpoint controllers, these parameters
and settings are marked by a superscript “F” (e.g. rampF), for program controllers /generators
by a “P”.
Selectors
Selectors are menus which fold down when an individual parameter is selected.
Two standard selectors are defined for the configuration tables below, for reasons of clarity:
Switched off
Analog Imp. 1
...
Analog Imp. 4
Math 1
...
Math 8
Process value C1
Setpoint C1
Ramp end C1
Control dev. C1
Output C1
Process value C2
Setpoint C2
Ramp end C2
Control dev. C2
Output C2
Process value C3
Setpoint C3
Ramp end C3
Control dev. C3
Output C3
Switched off
Measurement of analog input 1
...
Measurement of analog input 4
Result of math formula 1
...
Result of math formula 8
Process value for controller 1
Setpoint for controller 1
Ramp end value for controller 1
Control deviation for controller 1
Output for controller 1
Process value for controller 2
Setpoint for controller 2
Ramp end value for controller 2
Control deviation for controller 2
Output for controller 2
Process value for controller 3
Setpoint for controller 3
Ramp end value for controller 3
Control deviation for controller 3
Output for controller 3
