72 - 1150
C
ONFIGURATION
Selection of functions
Logic input 1 (2 to 6) / ...
Limit comparator (2 to 16) / ...
Logic 1 (2 to 8) / ...
Control contact 1 (2 to 8) / ...
Tolerance band signal / ...
Program end signal / ...
Ramp end signal 1 (2 to 4) / ...
Value / selection Description
Start Tune C1
Cancel Tune C1
Manual/Auto C1
Inhibit Manual C1
Start Tune C2
Cancel Tune C2
Manual/Auto C2
Inhibit Manual C2
Start Tune C3
Cancel Tune C3
Manual/Auto C3
Inhibit Manual C3
Start Tune C4
Cancel Tune C4
Manual/Auto C4
Inhibit Manual C4
Ramp stop C1
Cancel ramp C1
Setpoint switching C1
Proc. val. switching C1
Paramset switching C1
Ramp stop C2
Cancel ramp C2
Setpoint switching C2
Proc. val. switching C2
Paramset switching C2
Ramp stop C3
Cancel ramp C3
Setpoint switching C3
Proc. val. switching C3
Paramset switching C3
Ramp stop C4
Cancel ramp C4
Setpoint switching C4
Proc. val. switching C4
Paramset switching C4
Key inhibit
Level inhibit
Text display
Display off
Display changeover
Acknowledgement LK
Prg.Auto/Man. switching
Inhibit prgramm start
Program start
Program stop
Program cancel
Program selection
Fast forward
Segment change
Start self-optimization for controller 1
Cancel self-optimization for controller 1
Changeover to manual mode for controller 1
Inhibit manual mode for controller 1
Start self-optimization for controller 2
Cancel self-optimization for controller 2
Changeover to manual mode for controller 2
Inhibit manual mode for controller 2
Start self-optimization for controller 3
Cancel self-optimization for controller 3
Changeover to manual mode for controller 3
Inhibit manual mode for controller 3
Start self-optimization for controller 4
Cancel self-optimization for controller 4
Changeover to manual mode for controller 4
Inhibit manual mode for controller 4
Ramp stop for controller 1
Ramp OFF for controller 1
Setpoint switching for controller 1
Process value switching for controller 1
Parameter set switching for controller 1 (0 = parameter set 1)
Ramp stop for controller 2
Ramp OFF for controller 2
Setpoint switching for controller 2
Process value switching for controller 2
Parameter set switching for controller 2 (0 = parameter set 1)
Ramp stop for controller 3
Ramp OFF for controller 3
Setpoint switching for controller 3
Process value switching for controller 3
Parameter set switching for controller 3 (0 = parameter set 1)
Ramp stop for controller 4
Ramp OFF for controller 4
Setpoint switching for controller 4
Process value switching for controller 4
Parameter set switching for controller 4 (0 = parameter set 1)
Key inhibit
Level inhibit
Text display
Screen OFF
Switch over screen templates
Acknowledgement of limit comparators
Changeover between automatic and manual
Program cannot be started
Program start
Program stop
Program cancel
Program selection (see below)
Dynamic speed increase of programm sequence
Segment change
