1150 - 51
C
ONFIGURATION
Analog inputs
Depending on the instrument version, up to four analog inputs are available. The
analog inputs are numbered in sequence (input 1 — 4) according to their slot
assignment.
Analog input 1 (2 to 4) / ...
Configuration
Analog inputs
Controller
Generator
Limit comparators
Outputs
Logic functions
Math / Logic
C-level
Display
Interfaces
Device data
Recording
Value / selection Description
Probe
No function No function
RTD 3-wire Resistance thermometer in 3-wire circuit
RTD 2-wire Resistance thermometer in 2-wire circuit
RTD 4-wire Resistance thermometer in 4-wire circuit
T/C int. Thermocouple (internal cold junction)
T/C ext. Thermocouple (external cold junction)
T/C const. Thermocouple (constant cold junction)
Pot Potentiometer
Heater current Heater current 0 to 50 mA AC
0 to 20 mA 0 to 20 mA
0 to 10 V 0 to 10 V
0 to 1 V 0 to 1 V
0 to 100 mV 0 to 100 mV
- 10 to + 10 V - 10 V to + 10 V
- 1 to + 1 V - 1 to + 1 V
- 100 to + 100 mV - 100 to + 100 mV
4 to 20 mA 4 to 20 mA
2 to 10 V 2 to 10 V
0,2 to 1 V 0,2 to 1 V
20 to 100 mV 20 to 100 mV
- 6 to 10 V - 6 to 10 V
- 0,6 to 1 V - 0,6 to 1 V
- 60 to + 100 mV - 60 to + 100 mV
Factory-set on analog input 2 to 4: No function
