22 - 1150

E

LECTRICAL

C

ONNECTIONS

Connection diagram

Terminal strip numerical assignment

ATTENTION!

The electrical connection must only be carried out by properly qualified personnel.

NOTE

The instrument version can be identified by means of the type code (See nameplate on
the housing).
