15
Technicaldata
6.7 electrical data
6.7.1 electrical data without bus control 24 V Dc
Connections Circular plug-in connector (M12 x 1, 8-pole)
Pilot valve
Operating voltage
24 V DC ± 10% - max. residual ripple 10 %
Power input max. 1 W
Output max. 100 mA per output
Display max. 20 mA per illustrated illuminated display (LED)
6.7.2 electrical data with as-interface bus control
Connections Circular plug-in connector (M12 x 1, 4-pole)
Profile S-B.A.E. (A/B slave, max. 62 slaves/master)
Operating voltage 29.5 V – 31.6 V DC (according to specification)
Outputs
Max. switching capacity
1 W via AS-Interface
Watchdog function integrated
Max. power consumption 120 mA
Power consumption input during
normal operation
(after current reduction;
valve + 1 end position reached) 90 mA
6.7.3 electrical data with Devicenet bus control
Connections Circular plug-in connector (M12 x 1, 5-pole)
Operating voltage 11 V – 25 V
Max. power consumption < 80 mA
Output Pull-in current current ≤ 50 mA
Holding current ≤ 30 mA
english
Type 8695
