INTRODUCTION

1-1. THE SQD200 OPERATING MODE

Before you start setting up your

SQD200

for the first time, be sure you know exactly what you want to do with

it. The

SQD200

offers a one operating mode, which results in a versatile video production tool for live event

staging and fixed installation applications.

* NOTE * :

We recommend resetting the device to its default values every time you set up your shows or

events (see the “Operating The SQD200” chapter).

This mode allows to display up to four live windows, while preserving seamless switching capabilities. Several

templates are available. The quadravision mode can simultaneously view no less than 6 layers (4 video or

live layers, 1 frame layer or background and 1 logo layer).

QUADRAVISION MODE
