4-3. WORKING WITH THE SQD200
Operating modes
The SQD200 offers 1 mode to work from: the Quadravision Mode .
Resetting default values
It is strongly recommended resetting all of the default values of your SQD200 unit before setting up your
shows and events. To do so, press the [EXIT/MENU] button and select Control in the menu by rotating the
corresponding knob. Then press the [ENTER] button to enter the Control sub-menu. Select Default Values
by rotating the scroll knob, and press the [ENTER] button to enter your choice to restart your SQD200 with
its factory settings. This operation should take approximately 30 seconds .
Your machine will reboot after the reset has taken place.
SQD200 color codes
Analog Way engineers have developed a handy, user friendly way of identifying machine status on the front
panel, via the use of color codes on the buttons of the machine. All new Analog Way machines use the same
codes, for quick recognition of the status of any device of the range, at any given time.
For the SQD200 , button color codes are as follows:
- Sources on the Main output are indicated in red when active,
- Sources on the Preview output are indicated in green when active,
- Buttons in the layer section turn red or green , depending on whether the selected layer is active in
respectively the Main or Preview window,
- Menu buttons are indicated in green ,
- Selecting a button with an available source or function will cause that button to blink green on the
preview, or red once it is on the Main output,
- TAKE button reacts as follows:
• If the take function is available, the button will appear in green .
• When the take function is active, it will light up red .
#1 = Source, Layer or Window is on Main
#2 = Freeze enable
#1 = Source or Layer is on Preview
#2 = Function available for modification
Button available for selection
Active Layer or Source for modification on Main
Active Layer or Source for modification on Preview
Stand-by button
Solid red:
Solid green:
Dim green:
Blinking red:
Blinking green:
Dim red:
