B&K Precision 5492BGPIB - Manual - Manual (Page 106)

Specifications
106
Med
12.0000 mA
1.20000 A
12.0000 A
1.0+0.150
1.0+0.150
1.0+0.150
0.50+0.150
0.50+0.150
0.50+0.150
0.25+0.150
0.25+0.150
0.25+0.150
2.0+0.150
2.0+0.150
2.0+0.150
Fast
12.000 mA
1.2000 A
12.000 A
1.0+0.20
1.0+0.20
1.0+0.20
0.5+0.10
0.5+0.10
0.5+0.10
3.0+0.10
3.0+0.10
3.0+0.10
Max. crest factor: 3.0 at full scale
(1) Specifications are for sine wave inputs >5% of the range
Maximum Input and Overload Current Protection: 2A/ 250V fuse.
Resistance (2-Wire and 4-Wire)
Accuracy ± (% of reading + % of range), 23°C ±5°C
Rate Range (1) Resolution
Full Scale
Reading
Test Current
Accuracy
(1 year)
Slow
120.000 Ω
1.2 0000 kΩ
12.0000 kΩ
12 0.000 kΩ
1.20000 MΩ
12.0000 MΩ
120.000 MΩ
1 mΩ
10 mΩ
100 mΩ
1 Ω
10 Ω
100
Ω
1 kΩ
119.999
1.19999
11.9999
119.999
1.19999
11.9999
119.999
1 mA
1 mA
100 μA
10 μA
10 μA
7.0/(10M+Rx) μA
7.0/(10M+Rx) μA
0.05 +0.008 (2)
0.03 +0.004 (2)
0.03 +0.004 (2)
0.03 +0.004
0.03 +0.004
0.10 +0.004
0.50 +0.008
Med 120.000 Ω
1.2 0000 kΩ
12.0000 kΩ
12 0.000 kΩ
1.20000 MΩ
12.0000 MΩ
120.000 MΩ
1 mΩ
10 mΩ
100 mΩ
1 Ω
10 Ω
100
Ω
1 kΩ
119.999
1.19999
11.9999
119.999
1.19999
11.9999
119.999
1 mA
1 mA
100 μA
10 μA
10 μA
7.0/(10M+Rx) μA
7.0/(10M+Rx) μA
0.05 +0.015 (2)
0.03 +0.008 (2)
0.03 +0.008 (2)
0.03 +0.008
0.03 +0.008
0.10 +0.008
0.50 +0.015
Fast 120.000
Ω
1.2
0000 kΩ
12.0000
kΩ
12 0.000 kΩ
1.20000 MΩ
12.0000 MΩ
120.000 MΩ
10
mΩ
100
mΩ
1 Ω
10 Ω
100
Ω
1 kΩ
10 kΩ
119.99
1.1999
11.999
119.99
1.1999
11.999
119.99
1 mA
1 mA
100
μA
10 μA
10 μA
7.0/(10M+Rx) μA
7.0/(10M+Rx) μA
0.05 +0.02 (2)
0.03 +0.02 (2)
0.03 +0.02 (2)
0.03 +0.02
0.05 +0.02
0.10 +0.02
0.50 +0.02
(1) In order to eliminate the noise interference, which might be induced to the test leads, it is
recommended to use a shielded test cable for measuring resistance above 120 k
Ω.
(2) Using REL function
Note: Rx is the measured resistance value.
