Specifications
105
Med
120.000 mV
1.20000 V
12.0000 V
120.000 V
750.00 V
1.50+0.200
1.50+0.150
1.50+0.150
1.50+0.150
1.50+0.150
0.50+0.200
0.50+0.150
0.50+0.150
0.50+0.150
0.50+0.150
0.10+0.200
0.10+0.150
0.10+0.150
0.10+0.150
0.10+0.150
0.30+0.300
0.30+0.200
0.30+0.200
0.30+0.200
0.30+0.200 (2)
1.0+0.300
1.0+0.200
1.0+0.200
1.0+0.200
1.0+0.200 (1)
Fast
120.00 mV
1.2000 V
12.000 V
120.00 V
750.0 V
1.50+0.30
1.50+0.20
1.50+0.20
1.50+0.20
1.50+0.20
0.20+0.15
0.20+0.10
0.20+0.10
0.20+0.10
0.20+0.10
0.50+0.15
0.50+0.10
0.50+0.10
0.50+0.10
0.50+0.10 (2)
1.5+0.15
1.5+0.10
1.5+0.10
1.5+0.10
1.5+0.10 (1)
Max. crest factor: 3.0 at full scale
(1) Specifications are for sine wave inputs >5% of the range
(2)
≤ 3×10 7 Volt-Hz at 750 VAC range
Maximum input voltage: 750 Vrms
≤3×10 7 Volt-Hz for all ranges
Input impedance: 1
MΩ±2% in parallel with capacitance <100 pF
Maximum DCV: 500V for all AC ranges
AC Current (True RMS, AC Coupling)
Resolution and Full Scale Reading
Rate Range Resolution
Full Scale
Reading
Burden Voltage (1)
& Shunt Resistor
Slow
12.0000mA
1.20000 A
12.0000 A (2)
0.1 μA
10
μA
100 μA
11.9999
1.19999
11.9999
<0.15 V / 10.1 Ω
<0.3 V / 0.1 Ω
<0.15 V / 10 mΩ
Med
12.0000mA
1.20000 A
12.0000 A (2)
0.1 μA
10
μA
100 μA
11.9999
1.19999
11.9999
<0.15 V / 10.1 Ω
<0.3 V / 0.1 Ω
<0.15 V / 10 mΩ
Fast
12.000mA
1.2000 A
12.000 A (2)
1 μA
10
μA
1 mA
11.999
1.1999
11.999
<0.15 V / 10.1 Ω
<0.3 V / 0.1 Ω
<0.15 V / 10 mΩ
(1) Typical voltage across the input terminals at full scale reading.
In 12A range,>10-12 A AC is readable for 20 seconds maximum
Accuracy
Rate Range
Accuracy (1 year) ± (% of reading + % of range),
23°C ±5°C (1)
10~20 Hz 20~50 Hz 50~2 kHz 2~10 kHz
Slow
12.0000 mA
1.20000 A
12.0000 A
1.0+0.080
1.0+0.080
1.0+0.080
0.50+0.080
0.50+0.080
0.50+0.080
0.25+0.080
0.25+0.080
0.25+0.080
2.0+0.080
2.0+0.080
2.0+0.080
