58
3.13.8 Setting the Amplitude
The following equation represents the relative
output amplitude voltage relationship between
the front-panel amplitude peak-to-peak setting
and the data point values in waveform memory:
𝑜𝑢𝑡𝑝𝑢𝑡 𝑣𝑜𝑙𝑡𝑎𝑔𝑒
=
𝐴𝑚𝑝𝑙𝑖𝑡𝑢𝑑𝑒 𝑝 − 𝑝 𝑠𝑒𝑡𝑡𝑖𝑛𝑔 𝑥 𝑑𝑎𝑡𝑎 𝑝𝑜𝑖𝑛𝑡 𝑣𝑎𝑙𝑢𝑒
4095
+ 𝑜𝑓𝑓𝑠𝑒𝑡
Where 4095 is the data point value range in
waveform memory.
Table 3-4: Relative Amplitude for Waveform Output
(Examples)
Front Panel
Amplitude
Setting
Data Point
Value
Relative Output
Amplitude Voltage
5V p-p 2047 2.5 V positive peak
5V p-p 0 0V (offset voltage)
10V p-p 2047 5V positive peak
3.13.9 Executing an Arbitrary Waveform
To load a waveform into execution memory,
specify its starting address and length in the
ARBITRARY menu.
1. Select the channel to ON.
