3.13.5 Creating an Arbitrary Waveform

You can create an arbitrary waveform using the

following methods:

* Enter individual data points

* Draw lines between data points

* Create a predefined waveform

* Combine any of these methods

NOTE

You can use the free downloadable software to

create arbitrary waveforms.

For more information, please visit

You can program any number of waveforms into

waveform memory, keeping in mind the

addresses where one waveform ends and the

other begins.

The waveform's frequency and amplitude are

influenced by the number of data points and

their value in the waveform.

3.13.6 Entering Individual Data Points

The most basic way to program an arbitrary

waveform is to enter data points for the

waveform, one data point at a time. While this

can become tedious the auto-increment function

helps this process.

To enter individual data points into waveform
