Version 11.00, May 2013
Rohde & Schwarz R&S ® CMW500 Wideband Radio Communication Tester 51
WiMAX™ specifications – mobile station and base station test
Standard IEEE 802.16e-2005, OFDMA
WiMAX™ RF generator
(prerequisite: R&S
® CMW-B110A/R&S ® CMW-B110D option)
Frequency range WiMAX™ band 1 2300 MHz to 2800 MHz
WiMAX™ band 2,
prerequisite: R&S
® CMW-KB036 option
3300 MHz to 3800 MHz
WiMAX™ band 3,
prerequisite: R&S
® CMW-KB036 option
5100 MHz to 5850 MHz
WiMAX™ WinIQSIM2™ (R&S ® CMW-KW700 option)
Arbitrary waveform file in line with IEEE 802.16e-2005,
OFDMA average power WIMAX_DL_3-BURST_46_5MS.WV
(PAR = 11.11 dB)
Output level range depending on PAR see general technical specifications
Output level uncertainty waveform file used:
WIMAX_DL_3-BURST_46_5MS.WV see general technical specifications
Output level resolution see general technical specifications
Signal quality
Error vector magnitude (EVM) ID_Cell = 0, permbase = 0, prbs_id = 0,
cp = 1/8, BW = 10 MHz,
bursts: FCH, DL-MAP, data PN15,
modulation type and coding rate
QPSK 1/2;
waveform file used:
WIMAX_DL_3BURST_46_5MS.WV < –40 dB, RMS
WiMAX™ RF analyzer (R&S ® CMW-KM700, R&S ® CMW-KM701 options)
FFT size 512, 1024
Bandwidth 3.5 MHz, 5 MHz, 7 MHz, 8.75 MHz,
10 MHz
Link direction uplink, downlink
Subcarrier allocation DL PUSC, UL PUSC,
uplink collaborative MIMO
Frequency range WiMAX™ band 1 2300 MHz to 2800 MHz
WiMAX™ band 2,
prerequisite: R&S
® CMW-KB036 option
3300 MHz to 3800 MHz
WiMAX™ band 3,
prerequisite: R&S
® CMW-KB036 option
5100 MHz to 5850 MHz,
for frequency exceptions for inherent
spurious response, see general technical
specifications
Level setting manual mode
Level range RF1 COM, RF2 COM –40 dBm to +27 dBm, RMS
Statistics
Statistical count 1 to 1000
Values current, average, minimum, maximum
Trigger
Trigger source BASE: external TRIG A,
BASE: external TRIG B,
GPRF: BB generator,
WiMAX™: IF power,
WiMAX™ signaling: frame trigger
