Version 11.00, May 2013
40 Rohde & Schwarz R&S ® CMW500 Wideband Radio Communication Tester
GPS specifications
Standard GPS
GPS RF generator (prerequisite: R&S ® CMW-B110A/R&S ® CMW-B110D option)
Frequency range GPS band
L1 1575.42 MHz
L2 1227.6 MHz
GPS WinIQSIM2™ (R&S ® CMW-KW620 option)
Arbitrary waveform file GPS_DEFAULT.WV (PAR = 3.66 dB)
Output level range depending on PAR see general technical specifications
Output level uncertainty waveform file used:
GPS_DEFAULT.WV see general technical specifications
Output level resolution see general technical specifications
DVB specifications
Standard DVB-T
DVB RF generator (prerequisite: R&S ® CMW-B110A/R&S ® CMW-B110D option)
Frequency range VHF band III
channels 5 to 12 174 MHz to 230 MHz
UHF band IV
channels 21 to 34 470 MHz to 582 MHz
UHF band V
channels 35 to 69 582 MHz to 862 MHz
DVB WinIQSIM2™ (R&S ® CMW-KW630 option)
Arbitrary waveform file DVB-T_SCRAMBLED_16QAM_3SEC_
TESTFILE.WV (PAR = 13.23 dB)
Output level range depending on PAR see general technical specifications
Output level uncertainty waveform file used:
DVB-T_SCRAMBLED_16QAM_3SEC_
TESTFILE.WV see general technical specifications
Output level resolution see general technical specifications
FM STEREO RADIO specifications
Standard FM STEREO RADIO
FM STEREO RADIO generator
(prerequisite: R&S
® CMW-B110A/R&S ® CMW-B110D option)
Frequency range FM 70 MHz to 110 MHz
FM STEREO RADIO waveforms (R&S ® CMW-KV645 option)
Arbitrary waveform file FM_M_M1K0_D75K0.WV
(PAR = 0.00 dB)
Output level range depending on PAR see general technical specifications
Output level uncertainty waveform file used:
FM_M_M1K0_D75K0.WV see general technical specifications
Output level resolution see general technical specifications
Signal quality RMS detector *SQRT(2)
Deviation error
waveform file used:
FM_M_M1K0_D75K0.WV < 1 %
