Definitions and Acronyms
Module – A module is a plug-in card within the T5 series console that is used to perform various console functions. The
modules are used for field wiring of the input and / or output of electrical signals between different equipment.
RS-232 – An IEEE standard for serial communication using a 9-pin connector.
RS-485 – An IEEE standard for serial communication using Shielded Twisted Pair or Unshielded Twisted Pair wiring.
RJ-45 – An IEEE standard connector for use in communications with Shielded Twisted Pair wiring. Usually data.
RJ-11 – An IEEE standard connector for use in communications using Shielded Twisted Pair wiring. Usually voice and fax.
2SM – 2-Wire Sensor Module (Intrinsically Safe)
ACIM – AC Input Module
AIM – 4-20mA Analog Input Module (Intrinsically Safe)
AST – Aboveground Storage Tank
ATG – Automatic Tank Gauge
CARB – California Air Resources Board
CM – Controller Module
DCE – Data Communication Equipment
DIM – Dispenser Interface Module
DTE – Data Terminal Equipment
DTU – Data Transfer Unit
DW/DWT – Double Wall/Double Wall Tank
EVR – Enhanced Vapor Recovery
FAST – Franklin Auto Setup Tool
FMS – Fuel Management Systems
IS – Intrinsically Safe
ISD – In-Station Diagnostic
LCD – Liquid Crystal Display
LIM – LonWork Interface Module
LLD – Line Leak Detection
NC – Normally Closed
NO – Normally Open
OTB – One Touch Button
PC – Personal Computer
PM – Probe Module (Intrinsically Safe)
PSM – Power Supply Module
QJM – Quick-Jump Menu
RTD – Resistance Temperature Detectors
RM – Relay Module
SCM – Secondary Containment Monitoring
SLLD - Statistical Line Leak Detection
STP – Submersible Turbine Pump
TPI – Turbine Pump Interface
TS-EMS – Environmental Monitoring System
TS-EXPC – Expansion Console
URL – Uniform Resource Locator for the internet
USB – Universal Serial Bus
UST – Underground Storage Tank
VFM – Vapor Flow Meter
V/L – Vapor to Liquid ratio
VRM – Vapor Recovery Monitoring
XML – eXtensible Markup Language
Related Documentation
The system installation and operation instructions, troubleshooting guide and console maintenance manual are provided
for your use in separate documents. Detailed installation and testing instructions for each type of leak detection sensor
are present in the relevant manual, and, likewise, the installation, testing, and programming of various upgrade kits and
optional accessories are also contained in separate manuals, addenda or in one of this document’s appendices.
TS-550 evo Series Fuel Management Systems Installation Guide (000-2170)
TS-550 evo Series Fuel Management Systems Operators Guide (000-2171)
