30
Group Name Parameter Name
Parameter
Default
Description Parameter Input
Reconciliation
Over Short Limit Percent (1.00%) Gives the allowed amount on variance report 0-100%
Over Short Limit Volume (130.0 gal)
Combines with the Over Short % to give allowed
volume variance
#
Sales (Yes)
The calculation of the variance will be based
on Sales, Deliveries or Tank Volume. If all are
selected, it will be based on the highest
Yes / No
Deliveries (Yes) Yes / No
Tank Volume (Yes) Yes / No
Autocalibration
Autostop Volume Coverage (100%)
How much volume must be used before the
Autocalibration stops.
#%
Autostop Level Coverage (80%)
How much level must be used before the
Autocalibration stops
#%
Autostop Number of Points
Coverage
(100)
How many tank chart points must be created
before Autocalibration stops.
#
Compliance
Tracking
Enable Notification (Yes)
Allows the system to notify user about compliance
warnings & alarms.
Yes / No
Assessment Time (12:00)
Determines the time that the system will assess
the compliance status.
Time
Secondary Containment Monitoring
Group Name Parameter Name
Parameter
Default
Description
Parameter
Input
Secondary Containment
Monitoring
Number of Containments
(0)
Select the number of containments present. 0 - 48
Containment N Name (Containment 1) Given name of the containment abc#
Enabled (Yes) Select Yes if this containment will be monitored. Yes / No
Pump Shutdown on Alarm (No) Do you want to disable the pump on a containment alarm?. Yes / No
Submersible Pump Module
(Relay module) Select the module that has control of the STP that is
associated with this containment.
Relay Module
Power Supply
Module
TPI (No) Select Yes if TPI is controlling the STP. Yes / No
Submersible Pump
Channel
(Relay 1) Select the channel that has control of the STP that is
associated with this containment.
Relay #
Pump #
Transducer (4-20mA Input 1) Select the transducer that is associated with this
containment.
4-20mA
#
Rules
Group Name Parameter Name Parameter Default Description Options
Rules : Rules are a logic-based programming that are driven off of “If” based Events and “Then” Based actions. Essentially: “If” this event occurs “Then”
the console will perform a specified action.
Rule – New Rule # Name (New Rule #) Given name of rule. abc#
Enabled (No) Yes to enable rule. Yes/No
Events: Events can be both “If” logic and “Or” Logic. Therefore you can have several events trigger the same action. “If” Event 1 “Or” Event 2
occurs the console will perform a specified action.
Event Type (New Alarm Occurred) Event type that triggers action. New Alarm Occurred;
Alarm Status Changed;
Application Event;
Scheduled
Category (Any) System that event occurs in to trigger
action.
Any, System, FMS, VRM,
SCM, Other
Code (Any) Error/Trouble Event Code that triggers
action.
(see below)
Device (Any) Device that created the alarm condition. Various
State (Any) State of alarm to trigger action. Various
Action: Actions are sequentially “Then” / ”And” driven. Therefore, “If” an Event occurs “Then” the console will perform Action 1 and then Action
2 and then Action 3.
Action Type (E-mail) Action that will occur upon event E-mail, Report, Relay, Tank
Testing, Line Testing, Sentinel
mode, Reconciliation, sound,
Notify SSA, Sample input,
STP Control, Generator
Address your,[email protected] Where it will send e-mail
Contact Generated What e-mail format is used Generated, Text, HTML, Other
Template Text E-mail Template HTML, Text, short text
OTB This sets up rules that are displayed on the One Touch Buttons (OTB) on the console’s Home page. The setup process is
that same as Rules (above).
