48
Displayed Alarm /
Warning
Device Description Recommended Actions
Line is not configured Line Specified line is not configured,
therefore line leak test will not be
performed.
Verify line programming. If necessary configure line.
Line Not Learned Line Specified line not learned. Complete learn process, if any learn alarms occur follow the
proper procedure. Refer to “LS500 Auto Learn Line Leak Detection
Installation & User’s Guide” FFS 000-2145 for more information.
Line Program Error
Detected
Line An error has been detected in the
programming of the specified line.
Verify programming of line under the setup menu.
Line Pump Request
Ignored
Engineering The line has called for the pump
to be turned on but another
application is currently using the
STP
Verify that other applications are operating properly. Contact Franklin
Fueling Systems’ Technical Services Dept. for support.
Marginal Pass of Gross
Leak Test
Line The last passed gross test
detected a leak just under the
3 gph threshold.
Verify there is no sign of leaks within any of the sumps. Run
additional tests. Refer to “LS500 Auto Learn Line Leak Detection
Installation & User’s Guide” FFS 000-2145 for more information.
Monthly Leak Test Failed Line The Console has detected a line
leak greater than 0.2 gph.
Inspect all sumps for product. Refer to “LS500 Auto Learn Line
Leak Detection Installation & User’s Guide” FFS 000-2145 for more
information.
Not Enabled Line Line testing has not been enabled. Verify no other alarm is present then enter the line control menu and
enable the line testing feature.
Precision Leak Test Failed Line 0.1 GPH Line leak test failed. Follow site policy on line leak procedures.
Pressure Transducer Fail Line The transducer is not being
detected by the console.
Inspect the wiring to the specified transducer and the channel it
terminates at. Refer to “LS500 Auto Learn Line Leak Detection
Installation & User’s Guide” FFS 000-2145 for more information.
Sudden Pressure Loss Line During a 45 minute quite period
the pressure was seen to drop by
a 2 times the learned 3 gph slope.
Inspect all sumps for product. Refer to “LS500 Auto Learn Line
Leak Detection Installation & User’s Guide” FFS 000-2145 for more
information.
TPI Alarms
Displayed Alarm /
Warning
Device Description Recommended Actions
Capacitor Failing TPI The STP controller is reporting a
capacitor failure.
Refer to the applicable Smart controller Installation guide for details.
Clogged Intake TPI The STP controller has reported
a dry run condition but the
associated tank shows a product
level above the intake.
Ensure proper programming of the TPI and calibration of the Smart
Controller. If correct, check for an obstruction on the PMA.
Communication Failure TPI Communication from the TPI to
the STP controller has failed. The
Console is seeing the controller
but the controller is not responding
to commands.
Verify all wiring connections. Call FFS Technical Services Department
for support.
Controller Type Error TPI The programmed controller type
does not match what the console
is detecting.
Verify proper programming of the TPI as well as the Smart controller
type and address.
Dry Tank TPI The STP Controller has reported
a dry run condition and the
tank level is at or below the
programmed intake.
Ensure proper programming of the TPI and calibration of the Smart
Controller. If correct, add fuel.
Extended Run TPI The STP controller is reporting an
extended run condition.
Refer to the applicable Smart Controller Installation guide for details.
Hardware Fault TPI The STP controller is reporting
is reporting a hardware fault
condition.
High Temperature TPI The STP controller is reporting a
high temperature condition.
Locked Rotor TPI The STP controller is reporting a
locked rotor rating.
Not Calibrated TPI The STP controller is reporting
that it has not been calibrated.
Open Circuit TPI The STP controller is reporting an
open circuit condition.
