40
TPI Setup
Group Name Parameter Name
Parameter
Default
Description Max Value
Power Supply
RS-485
TS-TPI Enable Interface (Yes) Enables TS-TPI options. Yes/No
Controllers A* Number of Controllers (2) Number of controllers to be connected 31
Controller 1 Name Unlead Pump 1 Given Name of the pump controller abc#
Enabled (Yes) Enables the controller. Yes / No
Type (Mag/ECO)
Type of controller used Variable Frequency
Smart
3 phase smart
Smart I
Mag / Eco
unknown
Address (1)
Unique address of the controller
30
Group (0) Controller group number (if a member of a group) 15
Tank (1) Tank associated with controller 48
Height (5.00 in)
Approximate distance of pump motor from tank
bottom
#
Number of Inputs (1) Number of inputs that will activate controller 32
Input 1 Type AC Input Module Select module that contains the input Modules listed
Channel Disp. 1/2 Unleaded Specific input that will activate the controller 12
Controller 2 Name Unlead Pump 2 Given Name of the pump controller abc#
Enabled (Yes) Enables the controller. Yes / No
Type (Mag/ECO)
Type of controller used Variable Frequency
Smart
3 phase smart
Smart I
Mag / Eco
unknown
Address (1) Unique address of the controller 30
Group (0) Controller group number (if a member of a group) 15
Tank (1) Tank associated with controller 48
Height (5.00 in)
Approximate distance of pump motor from tank
bottom
#
Number of Inputs (1) Number of inputs that will activate controller 32
Input 1 Type AC Input Module Select module that contains the input Modules listed
Channel Disp. 1/2 Unleaded Specific input that will activate the controller 12
* When in the Edit mode of Setup, an A will appear for AutoConfigure. When the AutoConfigure Option is used, the tank
gauge will locate all of the controllers that are properly wired in the system and identify them.
Note: All DIP switch settings for the FE Petro controllers should be set as stand alone controllers, with the exception of
the addressing. All controllers need to have a unique address that is NOT set to 0). Note that the SCIII must be
placed in slave mode for TPI to function.
