20
Communications
Group Name
Parameter
Name
Parameter
Value
Description Parameter Inputs
Serial Ports
COMM 1
Mode Network Connection (PPP)
Network Connection (PPP)
Veeder-Root
Franklin Fueling System (XML)
Baud Rate 57600 1200 - 57600
Data Bits 8 7 or 8
Parity None
odd
even
none
Stop Bits 1 1 or 2
COMM 2
Baud Rate 9600 1200 - 57600
Data Bits 8 7 or 8
Parity None
odd
even
none
Stop Bits 1 1 or 2
Response Timeout 8 #
RS-485
Baud Rate 9600 1200 - 57600
Data Bits 8 7 or 8
Parity None
odd
even
none
Stop Bits 1 1 or 2
Modem
Type Internal
None
Internal
External
Mode Franklin Fueling Systems (XML)
Network Connection (PPP)
Veeder-Root
Franklin Fueling System (XML)
Data Bits 8 7 or 8
Parity None
odd
even
none
Stop Bits 1 1 or 2
Country Code United States (Select country)
Protocols Veeder-Root Port 8001 #
Veeder-Root Client Timeout 0 #
Web Server Secondary Port 10001 #
E-Mail “From” Address [email protected] Address of sender (console). abc
SMTP Host your_smtp_host_address IP address of SMTP Host. #
SMTP Port 25 Port address of SMTP. #
Enable
Authentication
No
Data authentication (if required). Yes / No
Maximum
Queue Size
20
Maximum size of queue in Megabytes.
Retry Timeout 3600 Time, in seconds, that the console will wait
before attempting to resend the message.
Watchdog
Timeout
30 Time, in seconds, that the console self-
monitoring program waits when it expects
and error due to software or power quality
problems.
Enable
Debugging
(No) Select Yes if you would like more status
information to be stored in the Messages
file.
Yes / No
LON IFSF Node ID (1) Allows the T5 Series console to
communicate with an IFSF POS (Point of
Sale) System
0-127
System Sentinel Anyware
This section will be filled out automatically by System Sentinel Anyware using the Program EPS feature.
