Power Supply Module
The Power Supply is a non-intrinsically safe module that provides power to the T5 series console from line voltage rated 110 - 240
VAC. This module is two inches wide, occupies two slots and is located immediately to the right of the Controller Module.
The Power Supply Module has two AC / DC switching power supplies: one power supply is +5 V and the other is +24 V.
The Power Supply also has two relay outputs for use with remote annunciators and two low voltage inputs for emergency
generator applications.
Group Name Parameter Name
Parameter
Default
Description
Parameter
Input
Power Supply
TS-TPI Enable Interface (Yes) Enables TS-TPI options. Yes / No
Controllers Number of Controllers (0) The number of controllers being monitored 1-31
Controller # Name Pump 1 Descriptive name used to identify input abc #
Enabled (Yes) Enables the output Yes / No
Type (Unknown)
The type of FE Petro Smart Controller • Variable
Frequency
• Smart
• Smart 1
• 3 Phase Smart
208/380V
• Mag/Eco
• Unknown
Address (0)
The slave address of the controller as configured by the DIP
switches on the Smart Controller.
0 - 30
Group (0)
The Group number this pump is in. Put Pumps located in
similar products into the same group for Leveling or Priority
mode.
0 - 15
Tank (0) The tank number (where this Pump is located). 0 - 29
Height (5.00)
The height of the Pump Motor Assembly off of the bottom of
the tank in inches.
#
Number of inputs (0)
The number of inputs that will have control over activating
and deactivating this Pump.
0 - 32
Groups Number of groups (0) The number of Groups as assigned under controllers. 0 - 15
Group # Name Group 1 Descriptive name used to identify input. abc #
Mode (None)
Select the mode you want. (Refer to the TPI section for
more details).
Leveling
Priority
None
Mode: None
Master / Slave (No)
Select yes if you want both pumps to run during periods of
high demand.
Yes / No
Alternating (No)
Select yes if you want the pumps to alternate when hook
signals drop out.
Yes / No
Fault Shutdown (No)
Select yes if you want both pumps to shutdown upon an
alarm.
Yes / No
Mode: Leveling
Master / Slave (No)
Select yes if you want both pumps to run during periods of
high demand.
Yes / No
Fault shutdown (No)
Select yes if you want both pumps to shutdown upon an
alarm.
Yes / No
Mode: Priority
Reserve (20)
The percent of volume on the associated tank at which the
pump will switch control to the next pump in the group.
# %
Master / Slave (No)
Select yes if you want all pumps to run during periods of
high demand.
Yes / No
Fault shutdown (No)
Select yes if you want all pumps to shutdown upon an
alarm.
Yes / No
