25
Programming FMS Parameters
Here is where specific equipment parameters will be modified to match the site setup.
Fuel Management System
Group Name Parameter Name
Parameter
Value
Description
Max
Value
Fuel Management
System
Ullage Percent (95) Percent of tank level used to calculate space left. 70-100 %
Delivery Delay (15 min) Time after delivery when increase is reported. # min.
Correction Temperature (60.00 °F) Product temperature correction. # °
Static Tank Testing Monthly Leak Test Threshold (0.00 gpm) Static leak tolerance for testing tanks. # gpm
Yearly Leak Test Threshold (0.00 gpm) Static leak tolerance for testing tanks. # gpm
Gross Leak Test Threshold (0.05 gpm) Static leak tolerance for testing tanks. # gpm
Confidence (99%) Leak testing confidence. 90, 95, 97.5,
99 %
Minimum Leak Test Time (2 hr) Minimum amount of time used to test. 0-8
Maximum Leak Test Time (8 hr) Maximum amount of time used to test. 1-8
Alarm On Precision Leak Test
Failure
(No)
Used to produce an alarm upon failure.
Yes/No
Tanks Number of Tanks (0) Number of tanks in fuel system. 0-48
Tank # Name (Tank 1) Given name of tank. abc#
Type (Special 1) Type of tank. Std./Spcl.
Manifolded (No) Used for Manifolded tanks. Yes/No
Product # (1) Type of product in tank. 1-48
Delivery Threshold (200.0 gal) Amount of increase to report delivery. # gal
Theft Threshold (5.0 gal) Amount of decrease to report theft. # gal
Limits High High Product Volume Limit (10,000.0 gal) Product volume to produce alarm. # gal
High Product Volume Limit (10,000.0 gal) Product volume to produce alarm. # gal
High High Product Level Limit (96.00 in) Product level to produce alarm. # in
High Product Level Limit (96.00 in) Product level to produce alarm. # in
High Water Level Limit (2.00 in) Water level to produce alarm. # in
Low Product Volume Limit (0.0 gal) Product volume to produce alarm. # gal
Low Low Product Volume Limit (0.0 gal) Product volume to produce alarm. # gal
Probe Channel (Probe 1) Channel used for the probe in tank. Probe
Type (Standard 53) Type of probe used in this tank. Std./Spcl.
Ratio
(1 to 1 tip to
head)
Ratio of float movement in proportion to product level.
1:7-9 for use with moorman gauge interface.
1:1; 1:7; 1:9
Float Type (4 in gas) Type of float(s) used on probe. 4, 3, or 2 in.
Gas/Diesel,
Stainless,
Propane
Number of Floats (2) Specifies number of floats on probe. 1-2
Gradient (9.03000 µs/in) Speed of probe wire. # µs/in
Product Offset (0.00 in) Used for compensation of tank tilt. (see Appendix xx:
Calculating Tank Tilt).
# in
Water Offset (0.00 in) # in
Static Tank
Testing
Enable Continuous Testing (No) Enables continuous tank testing. Yes/No
Run Input Module Type (Power Supply)
Power
Supply
Run Input Module Number (1) 1
Run Input Channel Number (1) 1-2
SCALD Enable (No) Enables SCALD tank testing. Yes/No
Qualify (0 %) Required percent full to run SCALD test. # %
Special Tanks
Group Name Parameter Name Parameter Value Description Max Value
Fuel Management System
Special Tanks
Special # Shape (Horizontal cylinder) Physical shape of the tank.
Length (160.00 in) Length of tank in inches. # in
Diameter (96.00 in) Diameter of tank in inches. # in
