Relay Modules
Group Name Parameter Name Parameter Value Description Max Value
Relay Modules
Module # Channels (0) Number of channels in use per module.
1-8
Channel # Name (Relay 1) Given name of the channel. abc#
Enabled (Yes) Yes if the channel is in use. Yes/No
Type (Unknown) Equipment connected to the relays output. Unknown
Submersible
Alarm
Solenoid
Dispenser
Other
Polarity (Normal) Allows the polarity to be inverted. Normal, Invert
Logic (OR Logic) The type of logic that the gate will use to process incoming
signals.
OR, AND, XOR
Physically Wired As (Normally Open) How the relay is wired internally. NO, NC
Number of inputs (0) This adjusts the circuit to accommodate incoming signal levels. 1-32
Input # Type (Unknown) Type of module that is sending the signal. Unknown
Controller
Power Supply
AC Input
Probe
2-wire Sensor
3-wire Sensor
4-20 mA
Channel (LV Input 1) Determines which module is sending the signal. 1-2
