7-2
INSPECTION ITEMS CHART
Item Inspection Criteria Corrective Action
Power Source Within permissible limits (170 - 253 VAC) Adjust the power supply voltage
Voltage for 230 VAC drives; or (323 - 506) for
460 VAC drives; or (480-575) for
575 VAC drives.
Ambient Within permissible limits (-10 o to +50 o C) Investigate cause and make corrections
Temperature (+14 o to +122 o F) until environment is within permissible limits.
Ambient Within permissible limits (20 - 90% RH) Investigate cause and make corrections
Humidity No dew condensation or freezing until environment is within permissible limits.
Vibration Within permissible limit (0.6G or less) Investigate cause and make adjustments
until within permissible limits.
Noise Abnormal Audio Noise from cooling Contact the supplier where the Drive
fan, etc. was purchased.
Odor Smell or burning Contact the supplier where the Drive
was purchased.
Dust Dust accumulation on cooling fins, Clean and blow out with compressed air.
cooling fan, or on the control board.
Screws/ Check for any loosening Retighten as needed.
Connectors
the current, the amount of error will be large if the
frequency is low. Because of this, always use a CT with
as large a capacity as possible. See the following chart
and Figure 7-2 for recommended measurement devices.
MEASUREMENT POINTS AND METERS
Since the Drive's input/output voltage and current
contain high frequencies, selection of the wrong measur-
ing device can lead to gross miscalculations. When
using a CT (current-detection transformer) to measure
RECOMMENDED MEASUREMENT DEVICE CHART
Item Simple Measurement Precision Measurement
Input Voltage Tester Moving-Iron type voltmeter
Input Current Clamp Meter Moving-Iron type ammeter
Input Power — Electrodynamometer type wattmeter
Output Voltage Tester Rectifier type voltmeter
Output Current Clamp Meter Moving-Iron type ammeter
Output Power — Electrodynamometer type wattmeter
