LCD
GRAPHIC
FACTORY
FUNCTION DISPLAY SETTING DESCRIPTION SETTING
6-19
47 (cont'd) E Stage number indication for Pattern Operation,
requires Y3, Y4, and Y5 outputs, set Function
Code 47 equal - - EEE.
F Alarm indication in alarm trip mode,
requires Y2, Y3, Y4, and Y5 outputs, set
Function Code 47 equal - FFFF.
Stage
1
2
Y3
Off
Off
Y4
Off
On
Y5
On
Off
3
4 Off
On On
Off On
Off
5
6
7 On
On
On Off
On
On On
Off
On
Cause of trip
Terminal
Y2 (F) Y3 (F) Y4 (F) Y5 (F)
0 Off Off Off Off
1 OC1 Off Off Off On
2 OC2 Off Off On Off
3 OC3 and EF Off Off On On
4 OU1, OU2, OU3 Off On Off Off
5 LU Off On Off On
6 OL Off On On Off
7 OLU Off On On On
8 OH1, OH3 On Off Off Off
9 OH2, dbH On Off Off On
10 FUS On Off On Off
11 Er1, Er3 On Off On On
12 Er2 On On Off Off
13 Er4 On On Off On
14 Er5 On On On Off
15 Er6, Er7 On On On On
