LCD
GRAPHIC
FACTORY
FUNCTION DISPLAY SETTING DESCRIPTION SETTING
6-34
* 91 %R1 SET MOTOR #1 CALCULATED % PER UNIT RESISTANCE %
0.00 TO Percent of motor resistance.
50.00 %:
%R1 = R1 + Cable R x 100
V/ (
√
3 x I)
R1 is motor resistance;
Cable R is resistance of cable between drive
and motor; V is rated motor voltage.
* 92 %X SET MOTOR #1 CALCULATED % PER UNIT IMPEDANCE %
0.00 TO Percent of motor impedance.
50.00 %:
%X = X1 + X2 x XM/ (X2 + XM) + Cable X x 100
V/ (
√
3 x I)
X1, X2, XM are motor values;
Cable X is inductance of cable between drive
and motor; V is rated motor voltage.
93 DD FUNC 1 DO NOT USE
94 DD FUNC 2 DO NOT USE
95 DATA PRTC DATA PROTECTION 0
Once the Function Codes have been set, the
data protection can be activated and prevent
any further changes.
0: Not protected (changeable)
1: Protected (change prevented)
Press >> and UP Key together to change Function
Code 95 to 1.
Press >> and DOWN Key together to change Function
Code 95 to 0.
Press FUNC DATA to store change in software.
SPECIAL FUNCTIONS
