FUNCTION DISPLAY SETTING DESCRIPTION SETTING
6-1
00 FREQ COMND FREQUENCY COMMAND 0
Frequency reference can be supplied by
three different methods: Keypad
(digital), 0 to +10 VDC, 4 to 20 mA.
0: Keypad operation (Digital setting with
/\ or \/ keys).
1: 0 to +10 VDC analog signal (terminal 12),
or a speed potentiometer connected to
terminal 11, 12 and 13.
2: Sum of 0 to +10 VDC (terminal 12) and 4 to
20 mA (terminal C1).
NOTE : Drives 40HP & greater can use a 0
to + 10 VDC analog signal input (ter-
minal V1) which is summed with the
0 to +10 VDC input.
01 OPR METHOD OPERATION METHOD 0
RUN, STOP, and RESET commands can be
supplied by two different methods: Keypad
(local) or terminal strip (remote).
0: Keypad operation (RUN, STOP keys).
1: Terminal strip operation (Keypad STOP key active).
2: Terminal strip operation (Keypad STOP key inactive).
NOTE: Remote/local operation can be
toggled by pressing RESET and STOP
keys simultaneously when the
drive is in the STOP condition.
NOTE: Contact between FWD or REV and CM must
be open during power-up or "Er6" trip
will occur.
BASIC FUNCTIONS
NOTE: * = Function can be changed while the Drive is operating.
LCD
GRAPHIC
FACTORY
FUNCTION DISPLAY SETTING DESCRIPTION SETTING
Section 6: Function Code Descriptions
