GE Industrial Solutions AF-300E$ User Manual
Page 117
10-2
Catalog No.
Rating
Drive horsepower & quantity per drive
L" x W" x H"
Weight
0.5
1
2
3
5
7.5 10
15
20
25
30
lbs.
Kg.
AF-300E$ 230 VAC, 30 Hp and Below (continued)
Fuse
Cr6L150/UL
150A
1
1
1.5 x 4 x 1.5
0.3
0.14
Cr6L260/UL
260A
1
1
1.5 x 4 x 1.5
0.3
0.14
Charge Resistor
RBS40N5ROKI
5.0 Ohm 40W
*
*
*
*
*
*
*
2
2
2
2
4 x 1 x 1
0.2
0.091
AF-300E$ 460 VAC, 30 Hp and Below
Main Control Card
G9CPCBG4075
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG415
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG422
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG437
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG455
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG475
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG411
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG4150
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG4185
1
4 x 5.75 x 1.25
0.5
0.23
G9CPCBG4220
1
4 x 5.75 x 1.25
0.5
0.23
Base Driver & PS Card
G9PPCB4075CE
1
9 x 6 x 3
1
0.455
G9PPCB415CE
1
9 x 6 x 2
1
0.455
G9PPCB422CE
1
9 x 6 x 2.5
1
0.455
G9PPCB437CE
1
9 x 6 x 2
1
0.455
G9PPCB455CE
1
8.5 x 7.5 x 1
1
0.455
G9PPCB475CE
1
10 x 8 x 1
1
0.455
G9PPCB411CE
1
10 x 8 x 1
1
0.455
G9PPCB4150CE
1
10 x 8 x 1
1
0.455
G9PPCB4185CE
1
10 x 8 x 1
1
0.455
G9PPCB4220CE
1
10 x 8 x 1
1
0.455
Capacitor Unit
G9CU415
270uf
*
1
7.5 x 1.5 x 2
0.44
0.2
G9CU422
330uf
1
7.5 x 1.5 x 2
0.44
0.2
G9CU437
330uf
1
2.25 x 3 x 3
1
0.455
G9CU455
1500uf
1
2.25 x 3 x 3
1
0.455
G9CU475
2200uf
1
3 x 3 x 3
1
0.455
G9CU411
3300uf
1
3 x 4 x 4
2
0.91
G9CU4150
3900uf
1
4 x 3.5 x 3.5
2
0.91
G9CU4185
4700uf
1
4 x 4 x 4
2
0.91
G9CU4220
5400uf
1
4 x 4 x 4
2
0.91
Fan
G9FAN37
1
1
1
3 x 3 x 1
1
0.455
G9FAN75
1
1
5.5 x 3 x 1
1
0.455
G9FAN220
1
1
1
1
8 x 4.25 x 1
1
0.455
IGBT Gate Card
G9GPCB
1
1
1
1
5.5 x 1.25 x 1
0.044
0.02
Power Module
6MB150J120A
50A 1200V
*
*
*
*
1
1
4 x 1.5 x 1
0.8
0.364
CM75DY24H
75A 1200V
3
3
4 x 1.5 x 1
0.8
0.364
CM100DY24H
100A 1200V
3
3
4 x 2 x 1
1
0.455
* Located on Base Driiver and PS Card.
