3-12
Dimensions 150 Hp 460 VAC
Dimensions in inches (mm)
20.9 (530)
16.9 (430)
2-ø 0.6 (15)
0.7 (18)
AF-300E$
BACK PANEL MOUNTING
55.9 (1420) 57.1 (1450)
0.6 (15)
THROUGH PANEL MOUNTING
0.1 (3.2)
14.2 (360)
BACK PANEL 3.2
(80)
5.4
(136)
3.6
(92)
2.7
(68)
3.2 (81) 0.8 (20)
ø 1.9 (48)
wire inlet
Knock out hole
55.9 (1420)
20 (510)
16.9 (430)
0.5 (12.5)
54.9 (1395)
BACK PANEL
4-M12 0.5 5.5 (140)
3-ø 2.5 (64)s
NOTE: Drive includes a separately mounted DC Link Reactor.
AF-300E$ Back-Panel Mounting: Interior Watts Loss
Hp (CT) 0 setting 10 setting Hp (VT) 0 setting 10 setting
150 2050 2350 200 2050 2300
AF-300E$ Thru-Panel Mounting: Interior Watts Loss
Hp (CT) 0 setting 10 setting Hp (VT) 0 setting 10 setting
150 615 705 200 615 690
NOTE: Drive includes a separately mounted DC Link Reactor. See Page 4-10 for details
