3-14
Dimensions 250, 300 Hp 460 VAC
Dimensions in inches (mm)
26.8 (680)
22.8 (580)
2-ø 0.6 (15)
0.7 (18)
AF-300E$
BACK PANEL MOUNTING
56.3 (1430) 57.1 (1450)
THROUGH PANEL MOUNTING
4.5 (115)
14.2 (360)
26 (660)
22.8 (580)
0.4 (10)
55.7 (1415)
BRACKET REQUIRED FOR MOUNTING
2-M12 0.56 4.5 (115)
4-ø 0.6 (15)
BACK PANEL
BRACKET AREA
(BRACKET
SUPPLIED BY
OTHERS, MUST
BE CAPABLE OF
SUPPORTING
500 LBS. MIN.)
56.3 (1430)
BRACKET REQUIRED FOR MOUNTING
BRACKET AREA
(BRACKET
SUPPLIED BY
OTHERS, MUST
BE CAPABLE OF
SUPPORTING
500 LBS. MIN.)
24 (610)
2.4
(60)
4-ø 3.5 (90)
wire inlet
Knock out hole
4.3
(110)
6.7
(170)
4.9
(125)
5.3
(134)
1.6 (41)
3.9
(100)
43.
(1
10)
1.6 (40)
3
(75)
4 ø 1.9 (48)
wire inlet
Knock out hole
NOTE: Drive includes a separately mounted DC Link Reactor
AF-300E$ Back-Panel Mounting: Interior Watts Loss
Hp (CT) 0 setting 10 setting Hp (VT) 0 setting 10 setting
250 3500 4000 300 3450 3800
300 3850 4450 350 3900 4300
AF-300E$ Thru-Panel Mounting: Interior Watts Loss
Hp (CT) 0 setting 10 setting Hp (VT) 0 setting 10 setting
250 1050 1200 300 1035 1140
300 1155 1335 350 1170 1290
NOTE: Drive includes a separately mounted DC Link Reactor. See Page 4-10 for details
