FUNCTION DISPLAY SETTING DESCRIPTION SETTING
6-26
PATTERN OPERATION
65 PATTERN PATTERN OPERATION 0
A pattern operation can be set for seven
(7) individually set speeds (Function Codes
20 through 26) to run up to 6,000 seconds
each, forward or reverse direction (Function
Codes 66 through 72) with the following choice
of cycles:
0: Inactive
1: Single cycle
2: Continuous cycle (repeating)
3: Single cycle with continuous seventh speed
* 66 STAGE 1 PATTERN STAGES 0.00S:F1
* 67 STAGE 2 Each of the pattern operation’s seven (7)
* 68 STAGE 3 stages can be set based on the following
* 69 STAGE 4 codes that includes direction of rotation,
* 70 STAGE 5 selection of acceleration/deceleration
* 71 STAGE 6 times (Function Codes 5, 6, 33 through 38),
* 72 STAGE 7 and a maximum duration running time of 6,000
seconds each.
Code FWD/REV ACC/DECEL
F1 FWD ACC1/DEC1
0.00S:F1
F2 FWD ACC2/DEC2 0.00S:F1
F3 FWD ACC3/DEC3 0.00S:F1
F4 FWD ACC4/DEC4 0.00S:F1
R1 REV ACC1/DEC1 0.00S:F1
R2 REV ACC2/DEC2 0.00S:F1
R3 REV ACC3/DEC3 0.00S:F1
R4 REV ACC4/DEC4 0.00S:F1
Example: Function Code 66 set at 15.00F2
15:00 -Run time is 15 seconds to
include accel rate.
F2 -Foward direction, ACC2/DEC2
timing set in Function Codes
33 and 34.
NOTES: –If a stage’s timer is set at 0.00,
it will be skipped.
– /\ or \/ keys select the direction of
rotation, rate of acceleration and decel-
eration, and length of pattern stage run
time. The SHIFT >> key selects the digit of
the run time to be set using the /\ or \/ keys.
