LCD
GRAPHIC
FACTORY
FUNCTION DISPLAY SETTING DESCRIPTION SETTING
6-16
MOTOR #2
NOTE: Motor #2 is a second motor NOT multi-motor.
39 BASE Hz-2 BASE FREQUENCY #2 60
Base frequency for motor #2 is adjustable
from 30 Hz to 400 Hz in 1 Hz steps. Motor
#2 Function Codes become active when Function
Code 32 equals - - 1 and X5 – CM contacts are
closed.
(30 Hz to 120 Hz, 40 Hp & above, var. torque loads.)
WARNING: Review motor capabilities for operation above base frequency.
40 RATED V-2 RATED VOLTAGE #2 230
Maximum output voltage for motor #2 is (460)
adjustable from 80 to 240 V (230 V Drives)
or 320 to 480 V (460 V Drives). Motor #2
Function Codes become active when Function
Code 32 equals - - - 1 and X5 – CM contacts
are closed.
NOTE: When set at zero (0), the maximum
output voltage will follow the input
AC line voltage. (30 Hp & lower only)
* 41 TRQ BOOST2 TORQUE BOOST #2 2.0
Torque boost for motor #2 can be set to
optimize the V/Hz characteristics of the
drive according to the type of load the
motor will see. Motor #2 Function Codes
become active when Function Code 32 equals
- - - 1 and X5 – CM contacts are closed.
0.1 - 0.9: Variable torque loads
1.0 - 1.9: Proportional torque loads
2.0 - 20: Constant torque loads
* 42 43-51 FUNCTION CODE BLOCK DISPLAY 0
This setting determines whether or not
Function Code 43 through 51 will be
displayed and available for adjustment.
0: Function Code 43 through 51 NOT displayed.
1: Function Code 43 through 51 displayed.
