5-3
Press UP Key to Increase
Accel Time. >> Key Can
Shift Decimal Point.
STOP
PRG
→ DATA SET
>> → LED SEL
Program Mode Example of Checking Function Codes (Also Allows Changing Settings)
LCD Graphic Display
at Power Up
00 0
01 0
02 60 Hz
*03 60 Hz
Press DOWN Key to scroll
to Function Code 05,
which will be highlighted.
Press FUNC/DATA Key
*Would indicate a
change from
Factory Setting.
02 60 Hz
03 60 Hz
04 OV
05 6.00S
Press FUNC/DATA Key to
indicate setting and range
of setting.
Setting Blinks until FUNC/DATA
Key is pressed setting it in
Software and returning to the
next screen.
06 6.00S
07 0.0
08 1
09 14.5A
STOP
PRG
→ DATA SET
>> → LED SEL
Continue through Function
Codes or Press PRG Key to
Return to Operation Mode.
05 ACC TIME 1
6.00S
10.00S
Store F/D KEY →
05 ACC TIME 1
6.00S
0.01 3600 ˜
➪ DATA CHECK
I/O CHECK
TRIP IND CK
TRIP FACTOR
Press FUNC/DATA Key to
Display Function Code
settings.
→
→
→
→
→
→
→
