Fixing of the UPS cabinet TLE Series 225 – 500 on the floor
The UPS cabinet is free
standing and normally
does not require to be
bolted to the floor.
The UPS cabinet can be
fixed however to the floor
by bolting it with the
supporting blocks to the
floor.
Fig. 4.4.1.8 Fixing of the UPS cabinet on the floor
Fig. 4.4.1-9 TLE Series 225 & 250 – UPS cabinet floor fixing points
Fig. 4.4.1-10 TLE Series 400 & 500 – UPS cabinet floor fixing points
TLES_UL_225-50 0_S1_UPS fixing_0 1
2.13 " / 54 mm
2.37 " / 60 mm
44.10 " / 1120 mm
27.56 " / 700 mm 14.18" / 360mm
Ø 12mm /
0.48
"
TLES_160-200_S1_UPS fixing_01
FRONTAL SIDE
29.53
" /
75
0
m
m
34.06
" /
86
5
m
m
2.37 " / 60 mm
TLES_UL_400-500_S1_UPS fixing_02
29
.53
" / 750
m
m
2.37
" / 6
0 m
m
27.56 " / 700 mm
27.56 " / 700 mm
2.37 " / 60 mm
3.94 " / 100 mm
34
.06
" / 865
m
m
2.37 " / 60 mm
63.78 " / 1620 mm
2.13 " / 54 mm
Ø 0.48
" / 1
2m
m
FRONTAL SIDE
